Cycle Terminal

OEM Style Japanese Wiring  Connectors -  Sumitomo TS - .025 Sealed Series

TS025 (.64mm) Sealed Connectors,Terminals, and Wire Seals.

All connectors Come complete with terminal seal.

2 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12416

Sumitomo 6189-1161 Japan

               Female TS 025-2     $2.55 each

2 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12627

Sumitomo 6188-4797 Japan

                   Male TS 025-2     $2.35 each

Keep checking back for links on How to’s, Wiring Diagrams, and other great information.

If you have any Questions, please feel free to Email me Here

Economy  - Micro Open Barrel Crimp Tool

For JAE 040, Metri-pack GT150, Sumitomo 090 - 040 Terminals, Insulation and Wire Seals 16 - 30 AWG

Made in USA by Rostra

I have used this and  you can get factory quality crimps with it. This tool does the wire crimp, then the insulation or wire seal crimps in 2 steps.

If your not doing this type of crimping all the time, great tool to add to your box, and you cant beat the price. Pick up a few extra terminals to practice with.

These will not do Bullet terminals, or 110, 250 standard terminals

                                                          $33.95 each   ECT47

TS 025 Female Terminal

.2 - .5 mm (20-24 AWG)

Sumitomo Japan 8100-3455

$0.15 each

025 Female

TS 025 Wire Seal

Cable overall diameter

(mm) 1.5-1.7

Sumitomo Japan 7165-1199

$0.12 each

025 Seal

4 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Aftermarket housing

Sumitomo 6189-6948

Part name H2W025-4FAY-B

            Female TS 025-4  IAC   $3.70 each

Some applications include

Honda Suzuki late model IAC - Idle Air control valve connector

5 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12292

Sumitomo 6189-1046 Japan

                Female TS 025-5     $4.05 each

Some applications include

Toyota Lexus Scion - MAF - Mass air flow Sensor Connector - Tundra FRS

Toyota Lexus - Wave Radar Sensor

GM Duramax 6.6L MAF Sensor Connector

6 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12382

Sumitomo 6189-1142 Japan

               Female TS 025-6     $4.55 each

Yamaha motorcycle

Late model tail light connector

6 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12381

Sumitomo 6188-0706 - Aftermarket

                  Male TS 025-6      $4.25 each

Yamaha motorcycle

Late model tail light connector

TS 025 Wire Seal

Sumitomo Japan 7165-1312

$0.12 each

025 Plug

TS 025 Male Terminal

.2 - .5 mm (20-24 AWG)

Sumitomo Japan 8100-3617

$0.15 each

025 Male

8 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12520

Sumitomo 6189-1240 Japan

               Female TS 025-8     $3.55 each

Toyota-Lexus - Late model tail light connector

8 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12519

Sumitomo 6188-0779  Japan

                  Male TS 025-8      $3.45 each

Toyota-Lexus - Late model tail light connector

10 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12380

Sumitomo 6189-1134 Japan

               Female TS 025-10     $4.15 each

Toyota-Lexus - Late model tail light connector

Acura Honda - Wave Radar Sensor

10 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12379

Sumitomo 6188-0696  Japan

                  Male TS 025-10      $3.70 each

Toyota-Lexus - Late model tail light connector

6 pin TS 025  Female Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12790

Sumitomo  Japan

             Female TS 025-6T     $4.95 each

TS 025 Wire Seal

Sumitomo Japan 7165-0797

$0.12 each

025 Plug

6 pin TS 025  Male Connector

Comes with with Terminals and seals

Terminals Fit wire size .2 - .5 mm (20-24 AWG)

Toyota part # 90980-12303

Sumitomo 6189-1083 Japan

               Female TS 025-6B     $3.30 each
